5523W9A-4NVDECSAU1710
介绍5523W9A-4NVDECSAU1710面板开关,这是一种功能多样且高效的设备,旨在提升您的电气系统。该开关具有耐用的终端和衬套,确保安全连接和可靠性能。极数为单极,适用于各种应用。其电气功能可轻松实现ON OFF ON操作,提供灵活性和便利性。配备专为桨而设计的杠杆,该开关提供流畅而精确的控制。通过使用5523W9A-4NVDECSAU1710面板开关升级您的电气装置,体验无缝的功能。
规格
一般规格:
- 绝缘帽,强制,胶合在杠杆上:55600A、55200A 和 55200ZA 型号的 U270 55200WA 和 55200WA X433 型号的 U1040
- 接地连接器:如果面板不是金属或未接地,则必须使用 U721
- 环氧树脂密封端子标准
电气规格:
- I 类(正常绝缘)
- 小触点开口:µ (< 3 mm (.118))
- 电阻负载时的电流/电压额定值:3 A 250 VAC - 6 A 125 VAC
- 介电强度:2,000 Vrms 50 Hz 最小值。极之间以及端子和框架之间 1,000 Vrms 50 Hz min.端子之间
- 增加爬电距离和气隙的特殊主体:3 mm (.118)
